HEIDENHAIN iTNC 530 371
9.1
1
Pr
eassigned Q par
a
met
e
rs Measurement results from touch probe cycles (see
also User’s Manual for Cycle Programming)
Measured actual values Parameter value
Angle of a straight line Q150
Center in reference axis Q151
Center in minor axis Q152
Diameter Q153
Pocket length Q154
Pocket width Q155
Length of the axis selected in the cycle Q156
Position of the centerline Q157
Angle in the A axis Q158
Angle in the B axis Q159
Coordinate of the axis selected in the cycle Q160
Measured deviation Parameter value
Center in reference axis Q161
Center in minor axis Q162
Diameter Q163
Pocket length Q164
Pocket width Q165
Measured length Q166
Position of the centerline Q167
Determined space angles Parameter value
Rotation about the A axis Q170
Rotation about the B axis Q171
Rotation about the C axis Q172
