New functions in version 60642x-04
 A new NC syntax was introduced to control the adaptive feed rate
(AFC) function (see "Recording a teach-in cut" on page 449)
 You can now use the global settings to perform handwheel
impositioning in a tilted coordinate system (see "Handwheel
superimposition" on page 439)
 Tool names in a TOOL CALL can now also be called via QS string
parameters (see "Calling tool data" on page 199)
 The nesting depth for program calls has been increased from 10 to
30 (see "Nesting depth" on page 306)
 The new column ACC was introduced (see "Tool table: Standard
tool data" on page 184)
 The following new columns are available in the tool table:
 Column OVRTIME: Definition of the maximum permitted overrun of
service life (see "Tool table: Standard tool data" on page 184)
 Column P4: Possibility for transferring a value to the PLC (see "Tool
table: Standard tool data" on page 184)
 Column CR: Possibility for transferring a value to the PLC (see "Tool
table: Standard tool data" on page 184)
 Column CL: Possibility for transferring a value to the PLC (see "Tool
table: Standard tool data" on page 184)
 DXF converter:
 Bookmarks can be inserted when saving (see "Bookmarks" on
page 283)
 Cycle 25: Automatic detection of residual material added (see
User’s Manual for Cycle Programming)
 Cycle 200: Input parameter Q359 for specifying the depth reference
added (see User’s Manual for Cycle Programming)
 Cycle 203: Input parameter Q359 for specifying the depth reference
added (see User’s Manual for Cycle Programming)
 Cycle 205: Input parameter Q208 for the retraction feed rate added
(see User’s Manual for Cycle Programming)
 Cycle 205: Input parameter Q359 for specifying the depth reference
added (see User’s Manual for Cycle Programming)
