484

Programming: Special Functions

1

1

.15 F

reely definable tables

FN 26: TABOPEN: Opening a freely definable
table

With FN 26: TABOPEN you can define a table to be written with FN27,

or to be read from with FN 28.

Example: Open the table TAB1.TAB, which is saved in the
directory TNC:\DIR1.

Only one table can be open in an NC program. A new block

with TABOPEN automatically closes the last opened table.
The table to be opened must have the file name extension

.TAB.

56 FN 26: TABOPEN TNC:\DIR1\TAB1.TAB
