466 Programming: Special Functions
1
1
.1
1 Defining coor
dinat
e
tr
ansf
or
mations
Defining a program call
Using the program selection functions you can select any NC program
with the SEL PGM function and call it later with CALL PGM SELECTED. The
SEL PGM
function is also permitted with string parameters, so that you
can dynamically control program calls.
Define the program to be called
 Show the soft-key row with special functions
 Select the menu for defining various plain-language
functions
 Select the menu for functions for defining the
program selection
 Select the SEL PGM function: enter path names directly
or select the program via the SELECTION WINDOW
soft key. To enter a string parameter you press the Q
key and then enter the string number
Calling a selected program
 Show the soft-key row with special functions
 Select the menu for defining various plain-language
functions
 Select the menu for functions for defining the
program selection
 Select the CALL PGM SELECTED function: enter path
names directly or select the program via the
SELECTION WINDOW soft key. To enter a string
parameter you press the Q key and then enter the
string number
Example: NC blocks
13 SEL PGM “ROT34.H“
14 ...
33 CALL PGM SELECTED
34 ...
66 SEL PGM QS35
65 CALL PGM SELECTED
If you have selected a datum table in the TRANS DATUM
TABLE
block, then the TNC uses the programmed line
number only until the next call of a datum number
(blockwise effective datum shift).
If you did not define a datum table in the TRANS DATUM
TABLE
block, then the TNC uses the datum table already
selected in the NC program with SEL TABLE, or the datum
table with status M selected in one of the Program Run
modes.
