10 programming: miscellaneous functions – HEIDENHAIN iTNC 530 (60642x-04) User Manual
Page 41
HEIDENHAIN iTNC 530
41
10.1 Entering miscellaneous functions M and STOP ..... 382
10.2 Miscellaneous functions for program run control, spindle and coolant ..... 383
10.3 Miscellaneous functions for coordinate data ..... 384
Programming machine-referenced coordinates: M91/M92 ..... 384
Activating the most recently entered reference point: M104 ..... 386
Moving to positions in a non-tilted coordinate system with a tilted working plane: M130 ..... 386
10.4 Miscellaneous functions for contouring behavior ..... 387
Smoothing corners: M90 ..... 387
Inserting a rounding arc between straight lines: M112 ..... 387
Do not include points when executing non-compensated line blocks: M124 ..... 388
Machining small contour steps: M97 ..... 389
Machining open contour corners: M98 ..... 391
Feed rate factor for plunging movements: M103 ..... 392
Feed rate in millimeters per spindle revolution: M136 ..... 393
Feed rate for circular arcs: M109/M110/M111 ..... 394
Calculating the radius-compensated path in advance (LOOK AHEAD): M120 ..... 395
Superimposing handwheel positioning during program run: M118 ..... 397
Retraction from the contour in the tool-axis direction: M140 ..... 398
Suppressing touch probe monitoring: M141 ..... 399
Deleting modal program information: M142 ..... 400
Deleting basic rotation: M143 ..... 400
Automatically retract tool from the contour at an NC stop: M148 ..... 401
Suppressing the limit switch message: M150 ..... 402
10.5 Miscellaneous functions for laser cutting machines ..... 403
Principle ..... 403
Direct output of the programmed voltage: M200 ..... 403
Output of voltage as a function of distance: M201 ..... 403
Output of voltage as a function of speed: M202 ..... 404
Output of voltage as a function of time (time-dependent ramp): M203 ..... 404
Output of voltage as a function of time (time-dependent pulse): M204 ..... 404
