348 Programming: Q Parameters
9.8 A
d
ditional functions
5 0 Provides the active rotation angle
6 0 Provides the active value of the feed-rate override
7 1 to 9 (X to W) Provides 1 if the queried axis is disabled
8 1 to 10 (X to VT) Provides the max. value of the handwheel
superimposition in the queried axis
9 1 to 10 (X to VT) Provides the actual value of the handwheel
superimposition in the queried axis
11 1 to 7 Provides the values X Min, X Max, Y Min, Y Max, Z
Min
, Z Max, Set-up clearance
12 1 to 7 Returns the value 0 if the respective value is set to
inactive, otherwise 1. Index identical to FN18
ID332 NR11
13 0 Returns the selected coordinate system:
0=Machine, 1=Preset, 2=Workpiece
14 0 Machining at limit height mode: 0=do not
machine, 1=machine at limit
TS triggering touch probe, 350 10 - Touch probe axis
11 - Effective ball radius
12 - Effective length
13 - Radius setting ring
14 1 Center offset (reference axis)
2 Center offset (minor axis)
15 - Direction of center misalignment compared with
0° position
TT tool touch probe 20 1 Center point X axis (REF system)
2 Center point Y axis (REF system)
3 Center point Z axis (REF system)
21 - Probe contact radius
Last touch point in TCH PROBE
Cycle 0 or last touch point from
manual operating mode, 360
1 1 to 9 Position in the active coordinate system in axes 1
to 9
2 1 to 9 Position in the REF system in axes 1 to 9
Group name, ID no. Number Index Meaning
