3 Opening 3-D CAD data (sof
tw
ar
e option)
Operating the CAD viewer
Function Icon
Show shaded model
Show wire model
Show wire model without invisible edges
Adapt display size to screen size
Select standard 3-D view
Select plan view
Select view from below
Select view from left
Select view from right
Select view from front
Select view from behind
