690 MOD Functions
1
7.13 Selecting the ax
es f
o
r g
e
ner
a
ting L bloc
ks
17.13 Selecting the axes for
generating L blocks
Application
The axis selection input field enables you to define the current tool
position coordinates that are transferred to the L block To generate a
separate L block, press the ACTUAL POSITION CAPTURE key. The
axes are selected by bit-oriented definition similar to programming the
machine parameters:
Axis selection %11111: Transfer the X, Y, Z, IV, and V axes
Axis selection %01111: X, Y, Z, IV. Transfer the axis
Axis selection %00111: Transfer the X, Y and Z axes
Axis selection %00011: Transfer the X and Y axes
Axis selection %00001: Transfer the X axis
