724 Tables and Overviews
1
8
.2 Pin la
y
outs and connecting cables f
o
r the data int
e
rf
aces
When using the 9-pin adapter block:
Non-HEIDENHAIN devices
The connector layout of a non-HEIDENHAIN device may substantially
differ from that of a HEIDENHAIN device.
It depends on the unit and the type of data transfer. The table below
shows the connector pin layout on the adapter block.
TNC Connecting cable 355484-xx
Adapter block
363987-02
Connecting cable 366964-xx
Male Assignment Female Color Male Female Male Female Color Female
1 Do not assign 1 Red 1 1 1 1 Red 1
2 RXD 2 Yellow 2 2 2 2 Yellow 3
3 TXD 3 White 3 3 3 3 White 2
4 DTR 4 Brown 4 4 4 4 Brown 6
5 Signal GND 5 Black 5 5 5 5 Black 5
6 DSR 6 Violet 6 6 6 6 Violet 4
7 RTS 7 Gray 7 7 7 7 Gray 8
8 CTS 8 White/Green 8 8 8 8 White/Green 7
9 Do not assign 9 Green 9 9 9 9 Green 9
Hsg. External shield Hsg. External shield Hsg. Hsg. Hsg. Hsg. External shield Hsg.
Adapter block 363987-02 Connecting cable 366964-xx
Female Male Female Color Female
1 1 1 Red 1
2 2 2 Yellow 3
3 3 3 White 2
4 4 4 Brown 6
5 5 5 Black 5
6 6 6 Violet 4
7 7 7 Gray 8
8 8 8 White /
Green
7
9 9 9 Green 9
Hsg. Hsg. Hsg. External
shield
Hsg.
