HEIDENHAIN iTNC 530 347
9.8 A
d
ditional functions
7 U axis
8 5th axis
9 W axis
Status of M128, 280 1 - 0: M128 inactive, value not equal to 0: M128
active
2 - Feed rate that was programmed with M128
Status of M116, 310 116 - 0: M116 inactive, value not equal to 0: M116
active
128 - 0: M128 inactive, value not equal to 0: M128
active
144 - 0: M144 inactive, value not equal to 0: M144
active
Current system time of the TNC,
320
1 0 System time in seconds that have elapsed since
00:00 of January 1, 1970
Status of global program
settings GS, 331
0 0 0: No global program setting active,
1: A global program setting active
1 0 1: Basic rotation active, otherwise 0
2 0 1: Swapping axes active, otherwise 0
3 0 1: Mirroring axes active, otherwise 0
4 0 1: Shifting active, otherwise 0
5 0 1: Rotation active, otherwise 0
6 0 1: Feed rate factor active, otherwise 0
7 0 1: Disabling axes active, otherwise 0
8 0 1: Handwheel superimposition active, otherwise 0
9 0 1: Handwheel superimposition active in virtual
axis, otherwise 0
11 0 1: Limit plane active, otherwise 0
Values from global program
settings GS, 332
1 0 Value of basic rotation
2 1 to 9 (X to W) Provides the index of the axis on which the
queried axis was swapped: 1=X, 2=Y, 3=Z, 4=Y,
5=B, 6=C, 7=U, 8=V, 9=W
3 1 to 9 (X to W) Provides 1 if the queried axis is mirrored
4 1 to 9 (X to W) Supplies the shift value of the queried axis
Group name, ID no. Number Index Meaning
