HEIDENHAIN iTNC 530 189
5.2 T
ool data
LBREAK Permissible deviation from tool length L for breakage detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm
Input range in mm : 0 to 3.2767
Input range in inches
: 0 to +0.129
Breakage tolerance: length?
RBREAK Permissible deviation from tool radius R for breakage detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm
Input range in mm : 0 to 0.9999
Input range in inches : 0 to +0.03936
Breakage tolerance: radius?
Abbr. Inputs Dialog
