HEIDENHAIN iTNC 530 213
5.2 T
ool data
Sample import file:
 The CSV file to be imported must be stored in the
TNC:\system\tooltab
directory.
 If you import the tool data of tools whose numbers are
in the pocket table, the TNC issues an error message.
You can then decide whether you want to skip this data
record or insert a new tool. The TNC inserts a new tool
into the first empty line of the tool table.
 Make sure that the column designations are specified
correctly (see "Tool table: Standard tool data" on page
184).
 You can import any tool data, the associated data record
does not have to contain all the columns (or data) of the
tool table.
 The column names can be in any order, the data must
be defined in the corresponding order.
T,L,R,DL,DR Line 1 with column names
4,125.995,7.995,0,0
Line 2 with tool data
9,25.06,12.01,0,0 Line 3 with tool data
28,196.981,35,0,0
Line 4 with tool data
