97 FS2 Installation and Operation Manual — VIDEO 1 and VIDEO 2 Menu Groups
11.0 Proc Amp
(YUV) This parameter turns the Proc Amp On and Off for signals composed of YUV
components. When it is On, you can set additional parameters (11.1 to 11.4) to control
video Gain, Black Level, Hue, and Saturation. Proc Amp parameter settings are
independently kept for each separate input: SDI 1, SDI 2, Fiber 1, Fiber 2, Composite,
HDMI, and Component.
Note: Source Memory—Independent analog output timing values are kept for all
available output formats.
11.1 Proc Amp
Gain This parameter adjusts the video gain from 0 to 1.5 times luma in steps of .01, using
the ADJUST knob.
11.2 Proc Amp
Black This parameter adjusts the video black level from -20 IRE to +20 IRE in 0.5 steps, using
the ADJUST knob.
11.3 Proc Amp
Hue This parameter adjusts the video color hue through 360 degrees (color wheel). Steps
increment or decrement 1 degree using the ADJUST knob.
11.0 Proc Amp (YUV) Selections Selection Descriptions
Off (default)
On
Sets the YUV Proc Amp to Off.
Sets the YUV Proc Amp to On.
11.1 Proc Amp Gain Selections Selection Descriptions
Variable Adjusts Proc Amp Gain from zero to 1.5 in .01 steps.
Default (unity): 1.0
11.2 Proc Amp Black Selections Selection Descriptions
Variable Adjusts Proc Amp Black level from -20 IRE to +20 IRE in 0.5 steps.
Default (unity): 0 IRE
11.3 Proc Amp Hue Selections Selection Descriptions
Variable Adjusts Proc Amp Hue from -179 to +180 in steps of 1 degree.
Default (unity): 0 degrees
