163 FS2 Installation and Operation Manual — Video 1 & 2 Screens
Color Corrector
(RGB) Color Corrector turns the RGB Color Corrector On and Off. When it is On, you can set
additional adjustments to control video Gain, Black Level, and Gamma. When Color
Corrector is set to Off, all RGB color settings are programmed for unity (or bypass), and
the additional settings are hidden on this screen.
Note: Source Memory—Color Corrector values are independently kept for each
separate input: SDI 1, SDI 2, Fiber 1, Fiber 2, Composite, HDMI, and Component.
Color Red Gain Color Red Gain adjusts the RGB Red Gain from zero to 1.5 times in 0.01 increments.
Color Red Black
Level Color Red Black Level adjusts the RGB Red Black level from -20 IRE to +20 IRE in 0.5
steps.
Color Red
Gamma Color Red Gain adjusts the RGB Red Gamma by a factor of -1.0 to +1.0 in steps of 0.05.
Color Green
Gain Color Green Gain adjusts the RGB Green Gain from zero to 1.5 times in 0.01 increments.
(12.0) Color Corrector
(RGB)
Selections Selection Descriptions
Off (default)
On
Sets the Color Corrector to Off.
Sets the Color Corrector to On, enabling additional color adjustments.
(12.1) Color Red Gain Selections Selection Descriptions
Variable Adjusts Red Gain from zero to 1.5 in 0.01 steps.
Default (unity): 1.0
(12.2) Color Red Black
Level
Selections Selection Descriptions
Variable Adjusts Red Black level from -20 IRE to +20 IRE in 0.5 steps.
Default (unity): 0 IRE
(12.3) Color Red Gamma Selections Selection Descriptions
Variable Adjusts Red Gamma level from -1 to +1.0 in 0.05 steps.
Default (unity): 0
(12.4) Color Green Gain Selections Selection Descriptions
Variable Adjusts Green Gain from zero to 1.5 in 0.01 steps.
Default (unity): 1.0
