47 FS2 Installation and Operation Manual — Network Address
6. Run a browser on the computer and type in the IP address you set for the FS2.
You should now see the FS2’s Status screen.
When you can access the FS2 screens, turn to “Chapter 5: Browser Remote
Control” on page 123 for details about configuring the FS2 using a browser.
Setting FS2 Static IP Address
Turn the SELECT knob to scroll
to parameter menu 2.1 IP Config.
2.1 IP Config
STATIC Address
Select the CONFIG
Menu Group button
Parameter Menu
Current Setting
Change setting to
STATIC Address
by turning the
ADJUST knob.
Turn the SELECT knob to scroll
to parameter menu 2.2 IP Address.
Turn SELECT again as needed to
advance through the blinking octets.
2.2 IP Address
192.168.0.2 Parameter Menu
Current Setting
Push ADJUST to
edit octets.
Turn ADJUST
to change values.
Push ADJUST to save.
Turn SELECT to scroll to parameter
menu 2.3 Subnet Mask.
Turn SELECT again as needed to
advance through the blinking octets.
2.3 Subnet Mask
255.255.255.0 Parameter Menu
Current Setting
Push ADJUST to
edit octets.
Turn ADJUST
to change values.
Push ADJUST to save.
Turn SELECT to scroll to parameter
menu 2.4 Default Gateway.
Turn SELECT again as needed to
advance through the blinking octets.
2.4 Default Gateway
192.168.0.1 Parameter Menu
Current Setting
Push ADJUST to
edit octets.
Turn ADJUST
to change values.
Push ADJUST to save.
1
2
3
4
Select the CONFIG
Menu Group button
Select the CONFIG
Menu Group button
Select the CONFIG
Menu Group button
Config
Config
Config
SELECT ADJUST
SELECT ADJUST
SELECT ADJUST
SELECT ADJUST
Config
