162
Proc Amp (YUV) Proc Amp turns the Proc Amp On and Off for signals composed of YUV components.
When it is On, you can adjust additional settings to control video Gain, Black Level,
Hue, and Saturation. When Off, the additional settings are hidden. Proc Amp
parameter settings are independently kept for each separate input: SDI 1, SDI 2, Fiber
1, Fiber 2, Composite, HDMI, and Component.
Note: Source Memory—Independent analog output timing values are kept for
all available output formats.
Proc Amp Gain Proc Amp Gain adjusts the video gain from black to 1.5 times luma in steps of .01.
Proc Amp Black Proc Amp Black adjusts the video black level from -20 IRE to +20 IRE in 0.5 steps.
Proc Amp Hue Proc Amp Hue adjusts the video color hue through 360 degrees (color wheel). Steps
increment or decrement by 1 degree.
Proc Amp Sat Proc Amp Sat adjusts the video color saturation from black and white to 1.5 times
chroma in steps of .01.
(11.0) YUV Proc Amp Selections Selection Descriptions
Off (default)
On
Sets the YUV Proc Amp to Off.
Sets the YUV Proc Amp to On.
(11.1) Proc Amp Gain Selections Selection Descriptions
Variable Adjusts Proc Amp Gain from zero to 1.5 in .01 steps.
Default (unity): 1.0
(11.2) Proc Amp Black Selections Selection Descriptions
Variable Adjusts Proc Amp Black level from -20 IRE to +20 IRE in 0.5 steps.
Default (unity): 0 IRE
(11.3) Proc Amp Hue Selections Selection Descriptions
Variable Adjusts Proc Amp Hue from -179 to +180 in steps of 1 degree.
Default (unity): 0 degrees
(11.4) Proc Amp SAT Selections Selection Descriptions
Variable Adjusts Proc Amp Saturation from 0 (black & white) to 1.5 (Chroma) in
steps of 0.01.
Default: 1.0
