13.2 Custom
Aspect This parameter changes the H/V aspect ratio of the output picture while maintaining
the current V size (Aspect < 0) or H size (Aspect > 0). If Custom Size/Pos is On and this
parameter is not unity (0) for the current mode, the front panel UFC LED lights.
Custom Aspect is stored separately for each Conversion Mode. Values for each of the
Upconvert modes, Downconvert modes (excluding AFD), and SD Aspect Ratio modes
(excluding OFF), plus no conversion (or HD CrossConvert), are independently stored
(per Vid Proc).
13.3 Custom H
Position This parameter changes the H position of the output picture. If Custom Size/Pos is On
and this parameter is not unity (0%) for the current mode, the front panel UFC LED
lights.
Custom H Position is stored separately for each Conversion Mode. Values for each of
the Upconvert modes, Downconvert modes (excluding AFD), and SD Aspect Ratio
modes (excluding OFF), plus no conversion (or HD CrossConvert), are independently
stored (per Vid Proc).
13.4 Custom V
Position This parameter changes the V position of the output picture. If Custom Size/Pos is On
and this parameter is not unity (0%) for the current mode, the front panel UFC LED
lights.
Custom V Position is stored separately for each Conversion Mode. Values for each of
the Upconvert modes, Downconvert modes (excluding AFD), and SD Aspect Ratio
modes (excluding OFF), plus no conversion (or HD CrossConvert), are independently
stored (per Vid Proc).
13.2 Custom Aspect Selections Selection Descriptions
0.000 (default)
-0.500 to +0.500
Maintains the normal 100% aspect ratio for the selected format.
Enables changing the aspect ratio using the ADJUST knob.
13.3 Custom H Position Selections Selection Descriptions
0% (default)
-100% to +100%
Maintains the normal horizontal position of the selected format.
Enables changing the horizontal position using the ADJUST knob.
13.4 Custom V Position Selections Selection Descriptions
0% (default)
-100% to +100%
Maintains the normal 100% vertical position of the selected format.
Enables changing the vertical position using the ADJUST knob.
