FS2 Installation and Operation Manual — Network Pane and Network
Network Pane and Network Configuration Screen
The Network pane on the right side of any screen lists the FS2 systems that appear on
the network. This pane includes three additional controls:
•
Hover the cursor over any system name to see its IP address.
•
Right-click any system and select Identify to light the system ID LEDs.
•
Click the gear-shapped icon in the Network pane (or select Network from the
Menu list on the left side of the screen) to open the Network Configuration
screen listing FS2 network settings.
The Network Configuration screen allows you to view and change your FS2's network
settings and then click Apply to activate them. Detailed setup instructions for
connecting the FS2 to a network are included in Chapter 3, “Network Connection.”
FS2 Web Interface, Network Configuration Screen
Click the
Network
gear icon
