117 FS2 Installation and Operation Manual — AUDIO 1 and AUDIO 2 Menu Groups
assigned to channels x/y, any values assigned for the Audio Delay Ch x/y parameters
are ignored, and those menus are hidden.
If parameter 3 Audio Follow Video is set to On, the Audio Delay selection is
independently kept for each video input. If Audio Follow Video is set to Off, a single
Audio Delay value applies, regardless of the video input. (This value is independent of
any of the values used in Audio-Follow-Video mode.)
7.0 Audio
Output Levels This parameter enables or disables individual audio output level adjustment of the 16
audio output channels. When ADJUST is selected, parameters 7.1 through 7.16 set the
output levels for each separate channel.
d
Note: If parameter 3 Audio Follow Video is set to On, the Audio Output Levels
selection is independently kept for each video input. If Audio Follow Video is set to
Off, a single Audio Output Levels value applies, regardless of the video input. (This
value is independent of any of the values used in Audio-Follow-Video mode.)
7.1–7.16 Audio
Level Ch1–16 These 16 parameters adjust the audio levels of the 16 audio channels ± 18dB dB.
6.17-24 Audio Delay Selections Selection Descriptions
Variable Adjustment range increments from -16 to +256 mS or -768 samples
to +12288 samples.
Default=0 (synchronized to video output).
7.0 Audio Output Levels Selections Selection Descriptions
Unity (default)
Adjust
Disable audio output level adjustments and set levels to unity.
Enable audio output level adjustments for the 16 audio channels.
7.1–7.16
Audio Level Ch1–16
Selections Selection Descriptions
Variable Adjustment of audio level +/-18 dB range in steps of 0.5dB.
Default: +0dB
