133 FS2 Installation and Operation Manual — System Screen
System Screen
The System screen lets you select formats and specify input operation.
FS2 Web Interface, System Screen
Component In
Format Cmpnt In Format configures the format of the Component video input.
Component Out
Format Cmpnt Out Format configures the format of the Component video output.
(1) Cmpnt In Format Selections Selection Descriptions
SMPTE YPbPr (default)
Beta YPbPr
Composite (Y)
Configure the Component Video Input source as SMPTE YPbPr. This is
the default for HD component video.
Configure the Component Video Input source as Beta YPbPr (standard
definition).
Configure the Component Video Input source as composite, providing a
second composite input (requires version 1.1 firmware).
(2) Cmpnt Out Format Selections Selection Descriptions
SMPTE YPbPr (default)
Beta YPbPr
RGB
Composite (Y)
Configure the Component Video Output as SMPTE YPbPr. This is the
default for HD component video.
Configure the Component Video Output as Beta YPbPr (SD).
Configure the Component Video Output as RGB.
Configure the Component Video Output source as composite, providing
a second composite output (requires version 1.1 firmware).
