153 FS2 Installation and Operation Manual — Output Screen
Fiber1 3G Config The Fiber1 3G Config parameter determines how 1080p50/60 signals are formatted for
the Fiber 1 output. The first two choices select either "Level A” or "Level B” as
described in the SMPTE 425 standard. The third selection ties Fiber 1 Out and Fiber 2
Out together into a single 1.5 Gb Dual-link 1080p50/60output. In this case, the Fiber2
Video Out and Fiber2 Audio Out selections are ignored.
Fiber2 3G Config The Fiber2 3G Config parameter determines how 1080p50/60 signals are formatted for
the Fiber 2 output. The two choices select either "Level A” or "Level B” as described in
the SMPTE 425 standard. (If the Fiber1 selection is Dual Link, these Fiber2 settings are
ignored because the Fiber 2 output is used for dual link.)
(10.1) Fiber1 3G Config Selections Selection Descriptions
3 Gb-A (default)
3 Gb-B
1.5 Gb Dual Link
Sends 3 Gb format A 1080p 50/60 to the Fiber1 output.
Sends 3 Gb format B 1080p 50/60 to the Fiber1 output.
Sends dual-link 1.5 Gb 1080p 50/60 to the Fiber1 and Fiber2
outputs. As the term “dual-link” implies, the signals and
outputs are tied together.
(10.2) Fiber2 3G Config Selections Selection Descriptions
3 Gb-Level A (default)
3 Gb-Level B
Formats 3G SDI Output as Level A.
Formats 3G SDI Output as Level B.
