115 FS2 Installation and Operation Manual — AUDIO 1 and AUDIO 2 Menu Groups
3 Audio Follow
Video This parameter determines whether audio settings are remembered for each video
input. When AFV is On, The FS2 remembers the saved audio settings associated with
the currently selected video input. Whenever a new video input is selected, the
corresponding audio settings are recalled. This allows you to set up specific audio
settings for the different video inputs.
When AFV is Off, you must manually select the audio you want for a selected video
input, and that audio source remains selected until you change it. If the audio source
has never been selected, the factory default audio source is used.
Audio Follow Video applies to these parameters:
• 1 Audio Input
• 1.1—1.16 Audio Map
• 1.17—1.24 Audio Map (Stereo)
• 6.0 Audio Delay
• 7.0 Audio Output Levels
• 7.1—7.16 Audio Level Ch (n)
• 8.0 Audio Output Phase
• 8.1—8.16 Audio Phase Ch (n)
Note: Turning Audio Follow Video (AFV) On results in the loss of the above settings.
When AFV is turned On, the source-memory settings are written over the current
settings. Turning AFV Off again will not restore the original settings, but instead will
result in the source memory settings remaining in effect until edited again.
4 Audio SG This parameter determines the audio signal output from the FS2’s internal test signal
generator.
3 Audio Follow Video Selections Selection Descriptions
Off (default)
On
Normal operation. Audio settings must be made separately from any
video settings; they are not associated automatically.
The FS2 remembers the saved audio settings associated with the
currently selected input. Whenever an input is selected, the
corresponding audio settings will be recalled.
This allows you to set up specific audio settings for the different video
inputs (i.e., perhaps the SDI 1 has a specific embedded audio channel
mapping while the component video input might always use AES
audio input).
4 Audio SG Selections Selection Descriptions
Off (default)
400 Hz
1 kHz
Turn audio test signal output OFF.
Output a standard 400 Hz test signal tone.
Output a standard 1 kHz test signal tone.
