STATUS Menu Group
The Status Menu Group contains a series of Status display pages that you can scroll
using the SELECT knob. The various Status pages are actually just displays, not
menus, since they don’t include menu numbers or editable values. The ADJUST
knob doesn’t affect the Status display pages.
When you press the STATUS button, the display shows the first menu unless there is
an active alarm. If an alarm is active, the relevant alarm status page is displayed first.
If more than one alarm is active, the highest priority alarm page is displayed first.
Note: When displaying video format status, the following convention
differentiates between SMPTE video formats (broadcast) and computer (VESA/
DVI) formats (non-broadcast formats originating from a computer DVI signal).
The SMPTE formats are shown as height (in lines), scan-format (progressive or
interlaced), and frame-rate, such as 1080i59, for example. the VESA formats are
shown as a size only, with an x in the middle, such as 640x480, for example.
S.1 I/O Status This menu shows the current primary settings for Processors 1 and 2.
S.2 Vid1 Format
Status This menu shows the current primary settings for Processor 1.
S.3 Vid1 Format
Alarm Status This menu shows the Processor 1 alarm status. Absence of alarm shows as OK. If
selections are incompatible, the status of the affected signal shows incompat.
S.1 I/O Status
Parameter Def
Display Description
IN1 Sel Video Format
OUT1 Sel Video Audio
IN2 Sel Video Format
OUT2 Sel Video Audio
Processor 1 selected video input and detected format.
Processor 1 video output format and selected audio input.
Processor 2 selected video input and detected format.
Processor 2 video output format and selected audio input.
S.2 Vid1 Format Status
Parameter Def
Display Description
VID1 Input Source Format
BKGD Backgd Source
GEN Genlock Source Format
OUT Format
Selected Processor 1 video input source and format.
Selected Background video source.
Selected Genlock source and format.
Selected Processor 1 output format.
5.3 Vid1 Format Alarm
Status
Parameter Def
Display Description
VID1 Input Source Status
BKGD Backgd Source Status
GEN Genlock Source Status
OUT Status
Selected Processor 1 video input source alarm status.
Selected Background video source alarm status.
Selected Genlock source alarm status.
Selected Processor 1 output format/alarm status.
