128
IP Address Type IP Address Type determines the type of TCP/IP network configuration used by the
FS2. DHCP enables the FS2 to connect to the network DHCP server, which assigns
the IP Address, Netmask, and Gateway automatically. Static lets you set these
parameters manually. Networking is discussed in detail in Chapter 3, Network
Connection.) Consult your network administrator about how to set this value.
Note: If the IP Address Type is DHCP, the IP Address, Netmask, and Default Gateway
are gray, indicating they are set automatically and cannot be changed unless IP
Address Type is first set to Static. Changes are saved and activated upon
confirmation using the Apply button.
IP Address IP Address determines the static IP address used by the FS2 for TCP/IP networking.
(Networking is discussed in Chapter 3, Network Connection.) Consult your network
administrator about how to set this value.
Note: For the following selections, you will be setting multiple values separated
by periods (e.g., 90.0.181.0).
(2.1) IP Address Type Selections Selection Descriptions
DHCP (default)
Static Addr
Select automatic IP address assignment from the LAN DHCP server. If the
FS2 cannot find a DHCP server, it fails over to the static IP address.
Assign a static IP address manually (using parameters 2.2, 2.3, and 2.4).
The factory default static IP address: 192.168.0.2
(2.2) IP Address Selections Selection Descriptions
Variable If IP Address Type is set to DHCP, the IP address is set automatically by the
network DHCP server and cannot be entered here.
If IP Address Type is set to Static, enter an IP address compatible with your
LAN here. Also enter a netmask and default gateway address in the
following two parameters. Click Apply when you are ready to apply all
three entries to change the FS2's network addressing. If IP Address Type is
set to DHCP and there is a DHCP failure, the IP address is set to the static
IP address. The default static IP address is 192.168.0.2
