155 FS2 Installation and Operation Manual — Video 1 & 2 Screens
3. Dual Link—Dual Link referred to here is 1080p50/59.94 on two 1.5 Gb HD-SDI
connections. Selecting Dual Link as the Video Input for Video Processor 1 or 2 will
allocate both SDI Inputs for Dual Link use. Both Processors can use the Dual Link
Input, or if only one Processor is using it, the other Processor is free to select another
input. The Fiber inputs operate the same way.
4. I/O Limitations—Some frame rates are not available at the inputs or outputs with
the current software release. Additional frame rates will be supported in a future
release. Please see the Appendix A Specifications for affected frame rates.
Output Format The Output Format setting defines the output format of the Video Processor (1 or 2). The
scan format (progressive or interlaced) is set by the Video Input Scan Format setting. The
frame rate is set by the Frame Rates setting.
Notes:
1. Output Format Selection Constraint—Available frame rates depend on System 9
Frame Rates parameter setting.
2. Output Follow Ref Exception—If the Output Format is set to Follow Ref, and the
Genlock Source is set to Input, and the Video Input is set to select one of the analog
inputs, the output format will follow the input format rather than the format of the
signal on the Ref BNC as might be expected. (This combination of settings effectively
disconnects the Ref BNC.)
3. Output Timing Memory—Changing the Output Format selection automatically
selects new values for H & V timing parameters (Output Timing H, Output Timing V and
Analog Output Fine). Each Output Format mode remembers its own H and V timing
settings.
4. Output Format Mapping—The Output Format selection is remembered for each of
the frame rates. If you change the frame rate selection, the Output Format associated
with the newly selected frame rate is recalled.
5. I/O Limitations—Some frame rates are not available at the inputs or outputs with
the current software release. Additional frame rates will be supported in a future
release. Please see the Appendix A Specifications for affected frame rates.
(2) Output Format Selections Selection Descriptions
Follow INPUT (default)
Follow REF
525/625
720p
1080i
1080PsF
1080p
2K1080p
Follow the format of the selected input.
Follow the format of the reference input (Ref ).
Select 525/625 SD as the Video Processor output.
Select 720p HD as the Video Processor output.
Select 1080i HD as the Video Processor output.
Select 1080PsF HD as the Video Processor output.
Select 1080p HD as the Video Processor output.
Select 2K1080p HD as the Video Processor output.
