137 FS2 Installation and Operation Manual — System Screen
Frame Rates Frame Rates selects the HD video frame rate associated with the video standard.
NTSC Standard NTSC Standard selects the NTSC video standard.
Composite
Downconv Composite Downconv selects the type of Downconversion performed on the
incoming selected HD source input for the analog Composite (NTSC or PAL) video
output.
This parameter is used only when the Video Processor feeding the Composite output
(Output parameter 5 Composite Out) is producing HD. If that Video Processor is
producing SD, the Composite Downconverter is not needed, and the format on the
Composite output is the same as seen on the other outputs (controlled by parameter
7 Downconvert Mode for that Video Processor).
When the Downconverter is used, an additional frame of video delay is incurred and
the analog Composite output will be one frame behind the other outputs.
(9) Frame Rates Selections Selection Descriptions
59.94/23.98 (default)
50/25
60/24
Select 59.94/23.98 if your desired rate is either 59.94 or 23.98.
Select 50/25 if your desired rate is either 50 or 25 (PAL).
Select 60/24 if your desired rate is either 60 or 24.
(10) NTSC Standard Selections Selection Descriptions
NTSC (default)
NTSC Japan
Select NTSC to select the NTSC standard for North America.
Select NTSC Japan to select the NTSC standard for Japan.
(11) Composite
Downconv
Selections Selection Descriptions
Crop (default)
Anamorphic
14x9
Auto AFD
Letterbox
Image is cropped to fit new screen size.
HD image is converted to full-screen SD with a 16x9 aspect ratio
(anamorphic).
Image is reduced slightly with aspect ratio preserved. Black is added top
and bottom, and the left and right sides are cropped.
Automatically selects the best Downconvert mode based on the input
video's Active Format Description (AFD) code. If the input video is not
carrying an AFD VANC code, the Downconverter defaults to the mode
specified in parameter menu 16.3 Downconvert AFD Default.
Image is reduced with black top and bottom added to image area, with
the aspect ratio preserved.
