143 FS2 Installation and Operation Manual — Config Screen
SNMP Trap
Destination 1 This parameter determines the SNMP Trap Destination IP address where trap
messages issued by the FS2 will be sent. This parameter is available only if parameter
4.0 SNMP Enable is set to On.
Note: Set the IP address octets (numbers between periods) as follows:
Push ADJUST momentarily to enter edit mode.
Turn SELECT to select the octet you want to edit, indicated by blinking.
Turn ADJUST to enter the new value.
Push ADJUST momentarily to save and activate the new setting.
If you need to revert to the previous setting (undo changes), push SELECT. If you want
to revert to the default value, hold down ADJUST for 4 seconds.
SNMP Trap
Port 1 This parameter determines the SNMP Trap Port 1 used for sending destination #1 trap
messages. UDP Port 162 is the default used for SNMP trap messages. However, if this
port is being used by another protocol or service, you can change the setting by
modifying this parameter. This parameter is available only if parameter 4.0 SNMP
Enable is set to On.
Note: The SNMP Trap Port number does not blink when changed (as does the Trap
Destination IP address); if you change the port number and exit the parameter, the
port changes immediately to the new value.
(4.0) SNMP Enable Selections Selection Descriptions
Disable (default)
Enable 1
Enable Both
When set to Disable, the FS2 will not issue SNMP trap messages.
When set to Enable 1, the FS2 issues SNMP trap messages to Trap
Destination 1 (parameter 4.1) and as defined in the MIB.
When set to Enable Both, the FS2 issues SNMP trap messages to Trap
Destination 1 and 2 (parameters 4.1 and 4.3) and as defined in the MIB.
(4.1) SNMP Trap Dest 1 Selections Selection Descriptions
Variable Set the desired IP address where traps will be sent (usually a client on your
LAN). (See the note below for instructions.)
Default: 192.168.0.3
(4.2) SNMP Trap Port 1 Selections Selection Descriptions
Variable Turn the ADJUST knob to select a UDP port for sending FS2 trap messages.
Default: 162
