64
S.8 Caption
Status This menu shows what type of closed caption data is selected and whether closed
caption data is present on the selected video input.
S.9 Dolby Status This menu shows the FS2's Dolby Decoder settings.
S.10 Dolby
Framer Status This menu shows the current Dolby Framer status for Processors 1 and 2.
S.11 System
Name This menu shows the FS2's System Name, IP address and mask, and version number.
5.8 Caption Status
Parameter Def
Display Description
VID1CC Caption Type & Presence
ViD2CC Caption Type & Presence
Processor 1 selected caption type (SD/HD/Invalid) and
presence (Detected/Not detected/Pass through ).
Processor 2 selected caption type (SD/HD/Invalid) and
presence (detected/not detected/Pass through).
S.9 Dolby Status
Parameter Def
Display Description
DolbyDec
DolBDecM
DolBDAx0
DolBDAxM
Displays Dolby Status: Unknown, NotInstl, DolbyE, DlbyDgtl
or PCM.
Displays Dolby Decoder Mode setting: Auto, Dolby E or
Dolby D.
Displays Dolby Decoder Aux Out setting: Program1
(through) Program8.
Displays Dolby Decoder Aux Mode setting: Lt/Rt, Lo/Ro,
Mono, Mute.
S.10 Dolby Framer Status
Parameter Def
Display Description
Aud1
Frm1
Aud2
Frm2
Processor 1 Audio Dolby E Framer sync: Off, On, or Offset. For
On or Offset, shows the selected channel pair.
Processor 1 Audio Dolby E Framer: Locked or Unlocked.
Processor 2 Audio Dolby E Framer sync: Off, On, or Offset. For
On or Offset, shows the selected channel pair.
Processor 2 Audio Dolby E Framer: Locked or Unlocked.
S.11 System Name
Parameter Def
Display Description
System Name
IP addr
IP Mask
Version
Displays the System Name as set in Config menu 1.
Shows the FS2’s IP address.
Shows the FS2’s IP mask.
Shows the FS2’s software version number.
