181 FS2 Installation and Operation Manual — Audio 1 and 2 Screens
Audio Delay This Audio Delay setting applies to all audio input selections except Channel Map and
Stereo Map (described separately below). This setting allows you to adjust the audio
delay to compensate for video timing (delay/latency). You can set the delay from -16
to +256 mS -768 to +12288 (the default is zero delay).
If Audio Follow Video is set to On, the Audio Delay selection is independently kept for
each video input. If Audio Follow Video is set to Off, a single Audio Delay value applies,
regardless of the video input. (This value is independent of any of the values used in
Audio-Follow-Video mode.)
Note: the Delay menu for a particular channel-pair may be hidden if that channel pair
is controlled by the Dolby Framer (see 9.0 Dolby Framer Sync).
Audio Delay
Ch1-16 (Channel
Map)) These settings apply only when the audio input is set to Channel Map. The settings
allow you to adjust the audio delay for each audio channel to compensate for video
timing (delay/latency). Turning the ADJUST knob changes the delay from -16 to +256
mS or -768 to +12288 (the default is zero delay).
If parameter Audio Follow Video is set to On, the Audio Delay selection is
independently kept for each video input. If Audio Follow Video is set to Off, a single
Audio Delay value applies, regardless of the video input. (This value is independent of
any of the values used in Audio-Follow-Video mode.)
(6.0) Audio Delay Selections Selection Descriptions
Variable Adjustment range increments from -16 to +256 mS or -768 samples
to +12288 samples.
Default=0 (synchronized to video output).
(6.1-16) Audio Delay
Channel Map
Selections Selection Descriptions
Variable Adjustment range increments from -16 to +256 mS or -768 samples
to +12288 samples.
Default=0 (synchronized to video output).
