73 FS2 Installation and Operation Manual — CONFIG Menu Group
6.2 Vid2 Format
Alarm When set to Normal (default), an alarm is triggered whenever the selected input video
signal format of Video Proc 2 is incompatible with the selected output format (refer to
the matrix of inputs and compatibilities presented in Chapter 2). If you want the FS2
alarm to trigger only on hardware failures, you can suppress the Format Alarm. The
front panel Vid 2 FMT ERR LED lights when format errors are detected even if this
parameter is set to Suppress. The ADJUST knob changes the setting, and the change is
automatically saved.
7 Reference
Alarm This parameter controls how the FS2 responds when one of the Video Processors has
a format that is incompatible with the Reference video signal. When set to NORMAL,
the alarm triggers if the Reference signal is not detected or is incompatible with the
processor format. If you want the FS2 Reference alarm to trigger only on hardware
failures, you can suppress the alarm. The ADJUST knob changes the setting, and the
change is automatically saved.
8 Hidden Menus This parameter lets you choose whether to hide or show inactive menus.
9 Display
Intensity This parameter determines the brightness of the alphanumeric display and front
panel LEDs.
6.2 Vid 2 Format Alarm Selections Selection Descriptions
Normal (default)
Suppress
Alarm triggers if the format of the selected input video signal is
incompatible with the selected output format.
Alarm will not be triggered by a format incompatibility.
7 Reference Alarm Selections Selection Descriptions
Normal (default)
Suppress
Alarm triggers if the reference signal is not detected or is incompatible
with the processor format.
Alarm will not be triggered by reference errors.
8 Hidden Menus Selections Selection Descriptions
Hide Inactive (default)
Show All
Hides menus that are not in use.
Shows all menus, even those that are not in use.
9 Display Intensity Selections Selection Descriptions
Variable Turn the ADJUST knob to dim or brighten the alphanumeric display and
activity indicator LEDs in steps from 1 (dim) to 8 (brightest). Press
SELECT to revert to previous, or hold down ADJUST to restore the
factory default setting.
Default: 6
