145 FS2 Installation and Operation Manual — Config Screen
Display Intensity Display Intensity determines alphanumeric display and front panel LED brightness.
UPnP Host UPnP Host enables the FS2 to be discovered by a Windows network.
When this parameter is enabled, you can view the FS2 on a Windows Network by
clicking these selections in Windows 7: Start > Computer > Network (in left pane). Any
FS2s on the network will be listed under Other Devices below Computers and Media
Devices. If your system does not have network discovery enabled, you may need to
enable it following the Windows help instructions to make network devices visible in
the Windows Network window.
UPnP Proxy UPnP Proxy enables the FS2 to serve as a proxy for other AJA devices, allowing them
to be discovered on a Windows network through the FS2. When enabled, the FS2 acts
as a proxy for all the AJA devices that it is able to connect to that have not already
been discovered on the network. The devices will be listed in the FS2 Network
window. Once the devices appear on the network, they can connect directly to other
devices and computers without involving the FS2.
(9) Display Intensity Selections Selection Descriptions
Variable Use the slider to dim or brighten the alphanumeric display and activity
indicator LEDs in steps from 1 (dim) to 8 (brightest).
Default: 6
UPnP Host
Parameter Def
Display Description
Enable (default)
Disable
Enables the FS2 to be discovered by a Windows network.
Disables Windows network discovery of the FS2.
UPnP Proxy
Parameter Def
Display Description
Enable (default)
Disable
Enables the FS2 to connect other AJA devices to the network.
Disables the FS2 from serving as a proxy for AJA devices.
