Chapter 2:
Controls, Indicators, and Connections
2
Control and Indicator Descriptions
The controls, indicators, and connectors illustrated and described in this chapter
allow you to connect, operate, and monitor the FS2 system and to troubleshoot
problems if you encounter them. Becoming familiar with the FS2 front and rear
panels also simplifies system installation, setup, and operation.
Additional control, indicator, and connector details follow in these chapters:
• Full installation instructions are provided in Chapter 3.
• Detailed menu descriptions are presented in Chapter 4.
• The web browser user interface is described in Chapter 5.
Note: The AJA FS2 should be plugged into 3-wire 100-240 VAC 50/60 Hz
power (autosensing) before you make connections to other equipment. The
AC cords provide a path to ground for accidental static discharge to protect
system equipment. The FS2 has two fully independent and redundant power
supplies and will operate with one or both AC power cords plugged into the
unit. However, fault-tolerance exists only if both power supplies are
connected and plugged into separate branch circuits. Then if power is lost on
a branch or one of the supplies, the FS2 will continue to operate on the
remaining circuit and power supply.
Warning: To meet safety regulations for leakage current and to ensure
redundancy in the event that a branch circuit breaker shuts off a branch,
connect the FS2 dual power supplies to separate branch circuits.
