165 FS2 Installation and Operation Manual — Video 1 & 2 Screens
Custom Size/Pos Custom Size/Pos turns custom image settings On or Off. The custom settings
determine the image size and shape for Upconvert and Downconvert modes.
The Custom controls 13.1–13.8 are only displayed when Custom Size/Pos is On. When
Custom Size/Pos is Off, parameters 13.1–13.8 are skipped in the menu system, and the
UFC hardware is programmed for unity.
Note: this menu is not displayed when Active Format Description (AFD) is in control
of the Conversion Mode. While downconverting, with Downconvert Mode set to Auto
AFD, any values assigned for Custom Size/Pos parameters are ignored, and the menus
are hidden.
Custom Size Custom Size changes the H and V size of the output picture by the specified
percentage (%) while maintaining the current aspect ratio. If Custom Size/Pos is On
and this setting is not unity (100%) for the current mode, the front panel UFC LED
lights.
Custom Size is stored separately for each Conversion Mode. Drag the slider to set the
value. Values for each of the Upconvert modes, Downconvert modes (excluding AFD),
and SD Aspect Ratio modes (excluding OFF), plus no conversion (or HD
CrossConvert), are independently stored (per Vid Proc).
Custom Aspect Custom Aspect changes the H/V aspect ratio of the output picture while maintaining
the current V size (Aspect < 0) or H size (Aspect > 0). Drag the slider to set the value. If
Custom Size/Pos is On and this setting is not unity (0) for the current mode, the front
panel UFC LED lights.
(13.0) Custom Size/Pos Selections Selection Descriptions
Off (default)
On
Sets this selection and related custom size/pos parameters to
off.
Enables this selection and related custom size/position
parameters.
(13.1) Custom Size Selections Selection Descriptions
100% (default)
10% to 200%
Maintains 100% picture size for the selected format.
Enables changing the picture size using the ADJUST knob.
(13.2) Custom Aspect Selections Selection Descriptions
0.000 (default)
-0.500 to +0.500
Maintains the normal 100% aspect ratio for the selected
format.
Enables changing the aspect ratio using the ADJUST knob.
