43 FS2 Installation and Operation Manual — FS2 Chassis Installation
Dolby Decoder Installation
The v1.1 software release supports Dolby Decoder cards in the right-hand option
card slot. Disconnect AC power, remove the top panel option cover, and install the
card in the right-hand slot as described above.
After installation, access the front panel or browser menus, and set these
parameters as you prefer for the Dolby option:
• System parameters 15, 22.2, 22.3, and 22.4
• Audio 1 and Audio 2 parameters 1.0–1.24
FS2 Chassis Installation
The following information will help you install the FS2 chassis correctly.
Physical
Requirements for
Mounting the
Chassis You can mount the FS2 chassis in two ways:
• Rackmounting—attach the FS2 (rear or front mounted) to a standard 19-
inch wide equipment rack. The chassis occupies only one vertical rack unit.
• Desktop—lay it on a horizontal flat surface.
Chassis Dimensions
When planning the equipment location, consider the chassis dimensions:
• Height—1 rack unit, 1.75 inches (4.5 cm)
• Depth—16 inches (40.65 cm)
• Width—17.5 inches (44.45cm)
• Weight—7.85 pounds, 3.56 kilograms
Cabling and Cooling Requirements
Observe these precautions when placing your FS2:
• Plan adequate space for cable routing from the back of the chassis. Ensure
that cable connectors are not stressed and cables are not bent or crimped.
• When rack mounting or stacking multiple FS2 chassis, ensure adequate
airspace for cooling around the FS2 units. Note the location of cooling
vents on all equipment next to the FS2 and ensure none are obstructed.
Note: FS2 units can be stacked vertically without limit as long as there is an
adequate supply of cool air around the FS2 vents.
Power
Requirements The FS2 requires the following input voltage and power.
• Input Voltage—Chassis: autosensing 100VAC to 240VAC, 50/60Hz,
fully redundant with both power supplies diode isolated.
• Power Consumption—55 Watts.
