140
Dolby Decoder
Input This menu selects the audio input pair used to feed compressed data to the Dolby
Audio Decoder (option).
Dolby Decoder
Mode The Dolby Decoder Mode determines the Dolby Decoder "Bitstream Detect Mode"
on the Dolby Decoder Card. In Auto mode, the Dolby Decoder decodes Dolby E,
Dolby Digital, or Dolby DigitalPlus bitstreams. If none of the above are detected, the
card passes the incoming audio as PCM.
In Dolby E mode, the Dolby Decoder only decodes Dolby E bitstreams, and mutes
its outputs if it detects anything else.
In Dolby D mode, the Dolby Decoder only decodes Dolby Digital or Dolby
DigitalPlus bitstreams, and mutes its outputs if it detects anything else.
Note: This menu is visible only if the Dolby Decoder Option is installed.
(15) Dolby Decoder Input Selections Selection Descriptions
Input Pair AES Ch1/2 SDI 2 Ch1/2 Fiber 2 Ch1/2
AES Ch3/4 SDI 2 Ch3/4 Fiber 2 Ch3/4
AES Ch5/6 SDI 2 Ch5/6 Fiber 2 Ch5/6
AES Ch7/8 SDI 2 Ch7/8 Fiber 2 Ch7/8
AES Ch9/10 SDI 2 Ch9/10 Fiber 2 Ch9/10
AES Ch11/12 SDI 2 Ch11/12 Fiber 2 Ch11/12
AES Ch13/14 SDI 2 Ch13/14 Fiber 2 Ch13/14
AES Ch15/16 SDI 2 Ch15/16 Fiber 2 Ch15/16
SDI 1 Ch1/2 Fiber 1 Ch1/2
SDI 1 Ch3/4 Fiber 1 Ch3/4
SDI 1 Ch5/6 Fiber 1 Ch5/6
SDI 1 Ch7/8 Fiber 1 Ch7/8
SDI 1 Ch9/10 Fiber 1 Ch9/10
SDI 1 Ch11/12 Fiber 1 Ch11/12
SDI 1 Ch13/14 Fiber 1 Ch13/14
SDI 1 Ch15/16 Fiber 1 Ch15/16
(16) Dolby Decoder Mode
Selections Selection Descriptions
Auto (default)
Dolby E
Dolby Digital
Automatically decode Dolby E, Dolby digital, Dolby DigitalPlus, or PCM.
Decode Dolby E only.
Decode Dolby Digital or Dolby DigitalPlus only.
