Page 106
106
16.1 Legalizer
White Clip
When the Video Legalizer mode is YUV or RGB, this parameter limits the white level
so that is does not exceed the adjusted limit. Limit can be set from +80 IRE to +120
IRE using the ADJUST knob.
16.2 Legalizer
Black Clip
When the Video Legalizer mode is YUV or RGB, this parameter limits the black level
to the adjusted limit. Limit can be set from -10 IRE to +20 IRE, using the ADJUST
knob.
16.3 Legalizer
Chroma Clip
When the Video Legalizer mode is YUV, this parameter limits the maximum chroma
level to the adjusted limit. The limit can be set from +60% to +140%, using the
ADJUST knob.
16.1 Legalizer White Clip
Selections
Selection Descriptions
Variable
Adjusts white clip level from +80 IRE to +120 IRE in 0.5 steps.
Default (unity): 100 IRE
15.2 Legalizer Black Clip
Selections
Selection Descriptions
Variable
Adjusts black level limit from -10 IRE to +20 IRE in 0.5 steps.
Default (unity): 0 IRE
16.3 Legalizer Chroma
Clip
Selections
Selection Descriptions
Variable
Adjusts chroma clip level from +60% to +140% in 0.5 steps.
Default (unity): 100 IRE
