75 FS2 Installation and Operation Manual — PRESET Menu Group
PRESET Menu Group
1 Recall Preset This parameter recalls an FS2 preset configuration from the selected storage register.
Twenty named and numbered storage registers are available
(1–20) ., together with a
read-only Factory Preset. A preset is a set of all System, Video 1/2, Audio 1/2, and
Output parameters as they were set at the time the preset was stored.
Caution: When you push the ADJUST knob to recall a configuration, the recalled
configuration immediately replaces the system’s existing configuration. All previous
settings are lost unless you have previously stored them in a user register or
computer file.
During recall, the display reads, Recalling until the recall is finished. On recall
completion, the displays shows the success or failure: Recalled, Failed, or Empty. A
failed or empty recall does not recall anything and leaves the FS2 as it was. (Preset
registers are empty until you store something in them.)
2 Store Preset This parameter stores the current FS2 configuration into one of twenty available
named and numbered preset configuration storage registers
(1–20) . A preset is a set
of all System, Video 1/2, Audio 1/2, and Output parameters as they are set at the time
the preset is stored.
During the store, the display reads, Saving until the store is finished. On store
completion, the display shows Complete or Failed. A failed store does not store
anything and leaves the preset register as it was. To retry a failed store, turn SELECT to
another preset number and then back to the desired preset number.
Interaction of
Presets and GPIs Triggering presets using GPI inputs offers considerable power but also requires some
care to avoid unexpected results. If you plan to trigger presets using GPIs, please see
the information about the
“Interaction of Presets and GPIs” on page 67 .
1 Recall Preset Selections Selection Descriptions
Recall
[Preset 1–20]
0
The display shows the current preset register number and name.
Turn ADJUST to select the preset number to recall (1-20), and then
push ADJUST momentarily to perform (take) the recall.
Recalls factory values. Turn ADJUST left one click from Preset 1 to see the
Factory Preset (Preset 0). Then push ADJUST momentarily to perform
(take) the recall. User preferences, network settings, and existing
Presets are not affected by recalling the Factory Preset.
2 Store Preset Selections Selection Descriptions
Store The display shows the current preset register number and name.
Turn ADJUST to select the preset number to store, and then push and
hold down ADJUST to perform (take) the store.
