167 FS2 Installation and Operation Manual — Video 1 & 2 Screens
Custom Right
Crop Custom Right Crop changes the Right picture crop position. Drag the slider to set the
position. If Custom Size/Pos is On and this setting is not unity (100%) for the current
mode, the front panel UFC LED lights.
Custom Right Crop is stored separately for each Conversion Mode. Values for each of
the Upconvert modes, Downconvert modes (excluding AFD), and SD Aspect Ratio
modes (excluding OFF), plus no conversion (or HD CrossConvert), are independently
stored (per Vid Proc).
Custom Top
Crop Custom Top Crop changes the Top picture crop position. Drag the slider to set the
position. If Custom Size/Pos is On and this setting is not unity (100%) for the current
mode, the front panel UFC LED lights.
Custom Top Crop is stored separately for each Conversion Mode. Values for each of
the Upconvert modes, Downconvert modes (excluding AFD), and SD Aspect Ratio
modes (excluding OFF), plus no conversion (or HD CrossConvert), are independently
stored (per Vid Proc).
Custom Bottom
Crop Custom Bot Crop changes the bottom picture crop position. Drag the slider to set the
position If Custom Size/Pos is On and this setting is not unity (100%) for the current
mode, the front panel UFC LED lights.
Custom Bottom Crop is stored separately for each Conversion Mode. Values for each
of the Upconvert modes, Downconvert modes (excluding AFD), and SD Aspect Ratio
modes (excluding OFF), plus no conversion (or HD CrossConvert), are independently
stored (per Vid Proc).
(13.6) Custom Right Crop Selections Selection Descriptions
100% (default)
+10.0% to +100.0%
Maintains the normal right side position of the selected
format.
Enables changing the right side position using the ADJUST
knob.
(13.7) Custom Top Crop Selections Selection Descriptions
100% (default)
+10.0% to +100.0%
Maintains the normal top position of the selected format.
Enables changing the top position using the ADJUST knob.
(13.8) Custom Bottom
Crop
Selections Selection Descriptions
100% (default)
+10.0% to +100.0%
Maintains the normal bottom position of the selected format.
Enables changing the bottom position using the ADJUST
knob.
