Output Timing H
Output Timing H adjusts Video Processor horizontal output timing with reference to
the genlock source already selected. When adjusting the horizontal timing (H), this
setting specifies a number of pixels to offset, from zero to full line width.
Adjustment range increments from 0 to the width of the line in pixels. This could be
720, 1280, or 1920, depending on the format already chosen.
Note: Output Timing Memory—Independent horizontal and vertical timing
values are kept for all available output formats.
Output Timing V
Output Timing V adjusts Video Processor vertical output timing with reference to the
genlock source already selected. When adjusting the vertical timing (V), this
parameter specifies a number of lines to offset, moving the screen up to a half a
frame up or down.
Note: Output Timing Memory—Independent horizontal and vertical timing
values are kept for all available output formats.
Extra Frame
Delay
Extra Frame Delay adjusts Video Processor output timing in 1 frame increments from
0 to 6 frames.
(15.1) Output Timing H
Selections
Selection Descriptions
Variable
Adjustment range increments from 0 to the width of the line in pixels. The
maximum varies, depending on the format already chosen.
Default: 0
(15.2) Output Timing V
Selections
Selection Descriptions
Variable
Adjustment range increments from half a frame up to a half a frame down
in single line increments. The maximum varies, depending on the format
already chosen.
Default: 0
(15.4) Extra Frame Delay
Selections
Selection Descriptions
Variable
Adjustment output timing from 0 to 6 frames down in one frame
increments.
Default: 0
