196
Video A/D, D/A
These specifications describe the digital video D/A and A/D converters:
•
12 bits
•
2x oversampled (HD)
•
4x oversampled (SD)
Audio Inputs and Outputs
These specifications describe the analog and digital audio inputs and outputs:
•
8-channel balanced analog I/O, DB-25F 25-pin connector (Tascam pinout)
•
16-channel AES/EBU I/O (BNC), DB-25F 25-pin connector
•
16-channel SDI/HD-SDI embedded
Audio Levels
These audio levels can be set via the front panel and browser menus:
•
+12dBu, +15dBu, +18dBu, +24dBu, (Full Scale Digital)
LAN
These specifications describe the Ethernet LAN connection:
•
10/100/1000 automatic configuration
•
Automatic cable crossover (auto MDI-X)
•
Embedded web server
•
SNMP
•
VTECS™ protocol for Remote Control Panel
RS-422
The RS-422 connector follows these specifications:
•
DB-15F: Reserved for future use.
GPI
The following specifications describe the GPI input and output connector:
•
DB-15F: single connector provides four inputs and four outputs. See Appendix B for a connector
pinout and GPI specifications.
