112
AUDIO 1 and AUDIO 2 Menu Groups
1.0 Audio Input This parameter performs input audio source selection for Audio Processor 1.
Multiple input sources may be present at all the connectors on the FS2 rear panel,
but the active input source routed through the FS2 is the one selected here.
Note: If parameter 3 Audio Follow Video is set to On, the Audio Input selection is
independently remembered for each video input. When Audio Follow Video is Off,
audio for each video input is not remembered and you must manually select the
audio source you want. If you have never manually selected the audio source, the
factory default audio selection is used.
1.0 Audio Input Selections Selection Descriptions
Embed SDI1 (default)
Embed SDI2
Embed Fiber1
Embed Fiber2
HDMI
Dolby Decode
Mute
Channel Map
Stereo Map
AES/EBU
Analog
Uses the embedded audio from the SDI 1 video input as the input
source.
Uses the embedded audio from the SDI 2 video input as the input
source.
Uses the embedded audio from the optional Fiber 1 video input as
the input source.
Uses the embedded audio from the optional Fiber 2 video input as
the input source.
Uses the embedded audio from the HDMI video input (8-ch) as the
input source. Input channels 9-16 are set to Mute.
Selects the Dolby Decoder output as the audio processor input.
Sets all input channels to Mute.
For the 16 channels of audio input, selects inputs according to Audio
Map parameters 1.1 through 1.16. Any of the 16 embedded
channels can be mapped to one of the 96 sources.
For the 16 channels of audio input, selects stereo inputs according to
Audio Map parameters 1.17 through 1.24. Any channel pair (8 pair
total) can be mapped to 48 different choices.
Selects the AES/EBU digital audio input (16-ch) as the input source.
Selects the Analog audio connector (DB25, 8-ch) as the input source.
Input channels 9-16 are set to Mute.
