FS2 Installation and Operation Manual — Video 1 & 2 Screens
Region of
Interest Left
This parameter sets the left boundary of the ROI when parameter 14.0 is on.
Region of
Interest Right
This parameter sets the right boundary of the ROI when parameter 14.0 is on.
Region of
Interest Top
This parameter sets the top boundary of the ROI when parameter 14.0 is on.
Region of
Interest Bottom
This parameter sets the bottom boundary of the ROI when parameter 14.0 is on.
(14.1) Region of Interest
Left
Selections
Selection Descriptions
Variable
(default=100%)
Sets ROI left boundary to 10-100% of full screen.
14.2 Region of Interest
Right
Selections
Selection Descriptions
Variable
(default=100%)
Sets ROI right boundary to 10-100% of full screen.
(14.3) Region of Interest
Top
Selections
Selection Descriptions
Variable
(default=100%)
Sets ROI top boundary to 10-100% of full screen.
(14.4) Region of Interest
Bottom
Selections
Selection Descriptions
Variable
(default=100%)
Sets ROI bottom boundary to 10-100% of full screen.
