185 FS2 Installation and Operation Manual — Audio 1 and 2 Screens
Dolby Framer
Input This parameter is visible only if 9.0 Dolby Framer Sync is set to On or Offset; the
parameter is hidden when 9.0 is set to Off.
The Dolby Framer Input can sync incoming Dolby E bit streams to the local reference
so they can maintain A/V sync when recorded onto VTRs or servers or when passing
through downstream facilities. Using the ADJUST knob, you can set which pair of
channels contains the Dolby E stream to output synchronized with the reference. The
Dolby Framer Input feature only works with Dolby E inputs.
Dolby Framer
Offset (Frames) This parameter is visible only if 9.0 Dolby Framer Sync is set to Offset; the parameter is
hidden when 9.0 is set to Off or On. The parameter adjusts the audio delay in frames,
providing a coarse timing adjustment.
Framer Offset
(Samples) This parameter is visible only if 9.0 Dolby Framer Sync is set to Offset; the parameter is
hidden when 9.0 is set to Off or On. The parameter adjusts the audio delay in samples,
providing a fine timing adjustment.
(9.1) Dolby Framer Input Selections Selection Descriptions
Ch 1/2 ADJUST knob sets Dolby output channel pair to be synchronized with
the reference: Ch 1/2, 3/4, 5/6, 7/8, 9/10, 11/12, 13/14, 15/16.
Default= Ch 1/2.
(9.2) Dolby Framer Offset
(Frames)
Selections Selection Descriptions
Variable (frames) ADJUST knob sets the delay of the Dolby E audio stream relative to the
video frame. The minimum setting is 0 frames and the maximum is
+6 frames.
(9.3) Dolby Framer Offset
(Samples)
Selections Selection Descriptions
Variable ADJUST knob sets the delay of the Dolby E audio stream relative to the
video frame. The minimum setting is -768 samples and the maximum
is +768.
