69 FS2 Installation and Operation Manual — CONFIG Menu Group
2.2 IP Address This parameter determines the static IP address used by the FS2 for TCP/IP
networking. (Networking is discussed in Chapter 3, Network Connection.) Consult your
network administrator about how to set this value.
Note: For 2.2 to 2.4, set the octets (numbers between periods) as follows:
Push ADJUST momentarily to enter edit mode.
Turn SELECT to select the octet you want to edit, indicated by blinking.
Turn ADJUST to enter the new value.
Push ADJUST momentarily to save and activate the new setting.
If you need to revert to the previous setting (undo changes), push SELECT. If you want
to revert to the default value, hold down ADJUST for 4 seconds.
2.3 Subnet Mask This parameter determines the subnet mask used by the FS2 for TCP/IP networking.
(Networking is discussed in Chapter 3, Network Connection.) Consult your network
administrator about how to set this value.
2.4 Default
Gateway This parameter determines the gateway or router used on your LAN for TCP/IP
networking. (Networking is discussed in Chapter 3, Network Connection.) Consult your
network administrator about how to set this value.
Without a properly configured default gateway (whether you have a router/gateway
or not), the FS2 will be unable to see other FS2s on the network, although you may
still be able to control this FS2 via a web browser. Also, without a proper gateway
defined, the discovery feature “Available FS2s—Click to Refresh” on the Network web
page will not work correctly and list other FS2s on the network.
2.2 IP Address Selections Selection Descriptions
IP Address variable If 2.1 is set to DHCP dynamic addressing (default), the IP Address is set
automatically by the network's DHCP server.
If 2.1 is set to Static Addr, manually enter an IP address. (See note below.)
If 2.1 is set to DHCP and there is a DHCP failure, the IP address is set to the
static IP address. The default static IP address is 192.168.0.2.
2.3 Subnet Mask Selections Selection Descriptions
Subnet Mask variable Enter a subnet mask compatible with your LAN. This is only needed for
Static IP configurations. (See the note for 2.2 for instructions.)
If 2.1 is set to DHCP, the Subnet Mask is set by the DHCP server and
cannot be changed by the user.
If 2.1 is set to Default Addr, the default Subnet Mask is 255.255.255.0
2.4 Default Gateway Selections Selection Descriptions
Gateway Address
variable
Enter the address of the gateway or router used to connect the FS2 to
the network. (See the note for 2.2 for instructions.)
Default: 192.168.0.1
