179 FS2 Installation and Operation Manual — Audio 1 and 2 Screens
Audio Map Ch1/
2 through Ch15/
16 When Stereo Map is selected, these Map parameters for Audio Channels 1/2–15/16
map a pair of audio sources to each audio output channel pair. Available source pair
selections for the audio output channel pairs are listed in the following table. The
default selections are AES Ch1/2–AES 15/16 for Audio Output Channels 1/2–15/16,
respectively.
Embedded
Audio Out This setting turns embedded audio in the Processor output video to On, Mute, or Off.
When set to On audio is embedded in the SDI video. When set to Off, no audio data is
embedded. When set to Mute, audio data is embedded but muted.
(1.17–1.24) Audio
(Stereo) Map Ch1/2–15/
16
Selections Selections Selections Selections
AES Ch1/2
AES Ch3/4
AES Ch5/6
AES Ch7/8
AES Ch9/10
AES Ch11/12
AES Ch13/14
AES Ch15/16
Analog Ch1/2
Analog Ch3/4
Analog Ch5/6
Analog Ch7/8
Analog Ch1/2
Analog Ch3/4
Analog Ch5/6
Analog Ch7/8
SDI 1 Ch1/2
SDI 1 Ch3/4
SDI 1 Ch5/6
SDI 1 Ch7/8
SDI 1 Ch9/10
SDI 1 Ch11/12
SDI 1 Ch13/14
SDI 1 Ch15/16
SDI 2 Ch1/2
SDI 2 Ch3/4
SDI 2 Ch5/6
SDI 2 Ch7/8
SDI 2 Ch9/10
SDI 2 Ch11/12
SDI 2 Ch13/14
SDI 2 Ch15/16 Fiber 1 Ch1/2
Fiber 1 Ch3/4
Fiber 1 Ch5/6
Fiber 1 Ch7/8
Fiber 1 Ch9/10
Fiber 1 Ch11/12
Fiber 1 Ch13/14
Fiber 1 Ch15/16
Fiber 2 Ch1/2
Fiber 2 Ch3/4
Fiber 2 Ch5/6
Fiber 2 Ch7/8
Fiber 2 Ch9/10
Fiber 2 Ch11/12
Fiber 2 Ch13/14
Fiber 2 Ch15/16 HDMI Ch1/2
HDMI Ch3/4
HDMI Ch5/6
HDMI Ch7/8
Dolby Ch1/Ch2
Dolby Ch3/Ch4
Dolby Ch5/Ch6
Dolby Ch7/Ch8
Dolby Aux
Mute
(2) Embed Audio Out Selections Selection Descriptions
On (default)
Mute
Off
Turn audio embedding On at the Processor output.
Embeds but mutes audio on the Processor output.
Turns audio embedding Off at the Processor output
