141 FS2 Installation and Operation Manual — System Screen
Dolby Decoder
Aux Out The Dolby Decoder outputs eight channels of decoded audio, plus an additional Aux
output which is a 2-channel (stereo) mixdown of one of the selected Dolby Programs
(1-8). This selection determines which of the Programs is used for the Aux mixdown.
In this context, Program is not the same as a physical input channel. To Dolby, a
Program is a related set of audio channels. For example, a 5.1 audio source requires 6
channels and is considered one Program. Consequently, there may be a varying
number of Programs available on a given Dolby E bitstream. It is possible to have up
to eight Programs on a single bitstream if eight discrete mono channels were
encoded.
Note: This menu is visible only if the Dolby Decoder Option is installed.
Dolby Decoder
Aux Mode The Dolby Decoder outputs eight channels of decoded audio, plus an additional Aux
output which is a 2-channel (stereo) mixdown of one of the selected Dolby Programs.
This selection determines how the Aux mixdown is produced. Lt/Rt produces a stereo
mixdown which takes rear surround channels into account (when available).
Selecting Lo/Ro produces a stereo mixdown using only the front channels, Mono
produces a mono mixdown, and Mute produces full quality, high fidelity silence.
Note: This menu is visible only if the Dolby Decoder Option is installed.
(17) Dolby Decoder Aux
Out
Selections Selection Descriptions
Program 1 (default)
Program 2
Program 3
Program 4
Program 5
Program 6
Program 7
Program 8
Set the Dolby Aux Output to a mixdown of Program 1
Set the Dolby Aux Output to a mixdown of Program 2
Set the Dolby Aux Output to a mixdown of Program 3
Set the Dolby Aux Output to a mixdown of Program 4
Set the Dolby Aux Output to a mixdown of Program 5
Set the Dolby Aux Output to a mixdown of Program 6
Set the Dolby Aux Output to a mixdown of Program 7
Set the Dolby Aux Output to a mixdown of Program 8
(18) Dolby Decoder Aux
Mode Lt/Rt
Selections Selection Descriptions
Lt/Rt
Lo/Ro
Mono
Mute
Produces an Aux stereo mixdown including the rear surround channels.
Produces an Aux stereo mixdown using only the front channels.
Produces an Aux mono mixdown.
Produces full quality high fidelity silence.
