83 FS2 Installation and Operation Manual — SYSTEM Menu Group
16 Dolby
Decoder Mode This parameter determines the Dolby Decoder "Bitstream Detect Mode" on the Dolby
Decoder Card. In Auto mode, the Dolby Decoder decodes Dolby E, Dolby Digital, or
Dolby DigitalPlus bitstreams. If none of the above are detected, the card passes the
incoming audio as PCM.
In Dolby E mode, the Dolby Decoder only decodes Dolby E bitstreams, and mutes its
outputs if it detects anything else.
In Dolby D mode, the Dolby Decoder only decodes Dolby Digital or Dolby DigitalPlus
bitstreams, and mutes its outputs if it detects anything else.
17 Dolby
Decoder Aux
Out The Dolby Decoder outputs eight channels of decoded audio, plus an additional Aux
output which is a 2-channel (stereo) mixdown of one of the selected Dolby Programs
(1-8). This parameter determines which of the Programs is used for the Aux mixdown.
In this context, Program is not the same as a physical input channel. To Dolby, a
Program is a related set of audio channels. For example, a 5.1 audio source requires 6
channels and is considered one Program. Consequently, there may be a varying
number of Programs available on a given Dolby E bitstream. It is possible to have up
to eight Programs on a single bitstream if eight discrete mono channels were
encoded.
16 Dolby Decoder Mode Selections Selection Descriptions
Auto (default)
Dolby E
Dolby D
Automatically decode Dolby E, Dolby digital, Dolby DigitalPlus, or PCM.
Decode Dolby E only.
Decode Dolby Digital or Dolby DigitalPlus only.
17 Dolby Decoder Aux
Out
Selections Selection Descriptions
Program 1 (default)
Program 2
Program 3
Program 4
Program 5
Program 6
Program 7
Program 8
Set the Dolby Aux Output to a mixdown of Program 1
Set the Dolby Aux Output to a mixdown of Program 2
Set the Dolby Aux Output to a mixdown of Program 3
Set the Dolby Aux Output to a mixdown of Program 4
Set the Dolby Aux Output to a mixdown of Program 5
Set the Dolby Aux Output to a mixdown of Program 6
Set the Dolby Aux Output to a mixdown of Program 7
Set the Dolby Aux Output to a mixdown of Program 8
