Presets Screen
The Presets screen allows you to save FS2 Preset Configurations into 20 separate
memory registers and recall the presets whenever needed. This screen also includes
Export and Import functions that allow exporting one or all FS2 presets to your
computer as files and importing exported preset files from your computer. A
displayed message indicates successful or failed saves, recalls, exports, and imports.
FS1 Web Interface, Presets Screen
Factory Preset Factory Preset recalls all editable video and audio parameters to their factory default
settings. Individual presets, user preferences, and Network settings, such as the IP
Address, are not affected.
Recall The Recall buttons recall saved FS2 preset configurations.
Caution: When you recall a Preset Configuration, the recalled preset
immediately replaces the system’s existing configuration. All previous settings
are lost unless you have previously stored them in another preset configuration
or an exported file.
