102
13.5 Custom Left
Crop This parameter changes the Left picture crop position. If Custom Size/Pos is On and
this parameter is not unity (100%) for the current mode, the front panel UFC LED
lights.
Custom Left Crop is stored separately for each Conversion Mode. Values for each of
the Upconvert modes, Downconvert modes (excluding AFD), and SD Aspect Ratio
modes (excluding OFF), plus no conversion (or HD CrossConvert), are
independently stored (per Vid Proc).
13.6 Custom
Right Crop This parameter changes the Right picture crop position. If Custom Size/Pos is On and
this parameter is not unity (100%) for the current mode, the front panel UFC LED
lights.
Custom Right Crop is stored separately for each Conversion Mode. Values for each of
the Upconvert modes, Downconvert modes (excluding AFD), and SD Aspect Ratio
modes (excluding OFF), plus no conversion (or HD CrossConvert), are
independently stored (per Vid Proc).
13.7 Custom Top
Crop This parameter changes the Top picture crop position. If Custom Size/Pos is On and
this parameter is not unity (100%) for the current mode, the front panel UFC LED
lights.
Custom Top Crop is stored separately for each Conversion Mode. Values for each of
the Upconvert modes, Downconvert modes (excluding AFD), and SD Aspect Ratio
modes (excluding OFF), plus no conversion (or HD CrossConvert), are
independently stored (per Vid Proc).
13.5 Custom Left Crop Selections Selection Descriptions
100% (default)
+10.0% to +100.0%
Maintains the normal left side position of the selected format.
Enables changing the left side position using the ADJUST knob.
13.6 Custom Right Crop Selections Selection Descriptions
100% (default)
+10.0% to +100.0%
Maintains the normal right side position of the selected format.
Enables changing the right side position using the ADJUST knob.
13.7 Custom Top Crop Selections Selection Descriptions
100% (default)
+10.0% to +100.0%
Maintains the normal top position of the selected format.
Enables changing the top position using the ADJUST knob.
