113 FS2 Installation and Operation Manual — AUDIO 1 and AUDIO 2 Menu Groups
1.1–1.16 Audio
Map Ch1–16 When Channel Map is selected in parameter 1, these Map parameters for Audio
Channels 1–16 map an audio source to each audio output channel. Available source
selections for the audio output channels are listed in the following table. The default
selections are AES Ch1–16 for Audio Output Channels 1–16, respectively.
1.1–1.16
Audio Map Ch1–16
Selections Selections Selections Selections
AES Ch 1
AES Ch 2
AES Ch 3
AES Ch 4
AES Ch 5
AES Ch 6
AES Ch 7
AES Ch 8
AES Ch9
AES Ch10
AES Ch11
AES Ch12
AES Ch13
AES Ch14
AES Ch15
AES Ch16
Analog Ch 1
Analog Ch 2
Analog Ch 3
Analog Ch 4
Analog Ch 5
Analog Ch 6
Analog Ch 7
Analog Ch 8 SDI 1 Ch 1
SDI 1 Ch 2
SDI 1 Ch 3
SDI 1 Ch 4
SDI 1 Ch 5
SDI 1 Ch 6
SDI 1 Ch 7
SDI 1 Ch 8
SDI 1 Ch 9
SDI 1 Ch10
SDI 1 Ch11
SDI 1 Ch12
SDI 1 Ch13
SDI 1 Ch14
SDI 1 Ch15
SDI 1 Ch16
SDI 2 Ch 1
SDI 2 Ch 2
SDI 2 Ch 3
SDI 2 Ch 4
SDI 2 Ch 5
SDI 2 Ch 6
SDI 2 Ch 7
SDI 2 Ch 8
SDI 2 Ch 9
SDI 2 Ch 10
SDI 2 Ch 11
SDI 2 Ch 12
SDI 2 Ch 13
SDI 2 Ch 14
SDI 2 Ch 15
SDI 2 Ch 16 Fiber 1 Ch1
Fiber 1 Ch2
Fiber 1 Ch3
Fiber 1 Ch4
Fiber 1 Ch5
Fiber 1 Ch6
Fiber 1 Ch7
Fiber 1 Ch8
Fiber 1 Ch9
Fiber 1 Ch10
Fiber 1 Ch11
Fiber 1 Ch12
Fiber 1 Ch13
Fiber 1 Ch14
Fiber 1 Ch15
Fiber 1 Ch16
Fiber 2 Ch1
Fiber 2 Ch2
Fiber 2 Ch3
Fiber 2 Ch4
Fiber 2 Ch5
Fiber 2 Ch6
Fiber 2 Ch7
Fiber 2 Ch8
Fiber 2 Ch9
Fiber 2 Ch10
Fiber 2 Ch11
Fiber 2 Ch12
Fiber 2 Ch13
Fiber 2 Ch14
Fiber 2 Ch15
Fiber 2 Ch16 HDMI Ch1
HDMI Ch2
HDMI Ch3
HDMI Ch4
HDMI Ch5
HDMII Ch6
HDMI Ch7
HDMI Ch8
Dolby Ch1
Dolby Ch2
Dolby Ch3
Dolby Ch4
Dolby Ch5
Dolby Ch6
Dolby Ch7
Dolby Ch8
Dolby Aux1
Dolby Aux2
Mute
